LiuSj JUnSt 10000W Wind Solar Hybrid System MPPT Charge Controller,12V/24V/48V with Dump Load Wind Turbine Generator Solar Panel Auto Regulator,220v

Product DescriptionFeatures:The controller is designed specifically for hybrid wind solar street light system, which can make the wind solar hybrid street light system of various resources to achieve the best configuration, of course, the controller with some simple Settings can also be used in household system.Intelligent design succinct structure,powerfulcontroll, stable performance, safety and reliability of the products.Choose MPPT Wind turbine charging ways, charging more efficiency than ordinary PWM way more superior. The boost charge function, solve the low charging efficiency problem of low wind speed (optional). Professional digital intelligent control.Specification:1, Rated System Voltage: 12V/24V AUTO2, Rated Wind Power: 10000W3,Rated Solar Power:10000W4,No-Load Current: 0.05A5,Controller Power Mode: Battery or Solar6,Maximum imput voltage: 60V7,DC Output Current: Equal to Battery Voltage8,Maximum Output Current: 30A9,Display Content: LCD Display10,Net Weight:2.2kg

• ●Scope of use:This Hybrid charge controller match all 12/24v battery, including Lithium Battery. Suit max 10000w wind generator and max 10000w solar panels for wind solar complementary system for home, boat, street light.
• ●Operational system:The wind turbine charging part adopts booster MPPT technology, which make it charge continuous and efficiently even in low wind speed. Stepless unloading function including an external dump-load resistance. Solar panel charging use PWM technology by MOS tube in series.
• ●Intelligent&stable system:The parameter will be set prefect auto after choose battery type. User also can adjust by own requirement. This system has been updated into more intelligent to can control charge voltage stable absolutely.
• ●Display&DC Load mode: Bigger LCD screen which easy to browse and handle. Two DC Load (output) with 4 output modes and each one can be set different model.
• ●Protection function: Reversed charging Protection of solar, over charge voltage/under voltage & Over load voltage Protection, battery reverse connects and open circuit protection, Lightning Protection, etc. modes. The controller provides a variety of output modes(light control, time control, morning light) feasible for various applications.
